Introduction to Timing Arcs

Timing arcs are a fundamental concept in digital design, especially when dealing with Field Programmable Gate Arrays (FPGAs) and Application-Specific Integrated Circuits (ASICs). A timing arc defines the timing relationship between input and output ports of a component or cell in a digital circuit. Understanding timing arcs is crucial for performing accurate timing analysis, optimizing design performance, and ensuring the reliability of digital systems. This report provides a comprehensive overview of timing arcs, their significance, and how to analyze them using Xilinx Vivado tools. It includes detailed explanations, examples, and specific commands to help you effectively manage timing arcs in your FPGA designs.

What Are Timing Arcs?

A timing arc represents the timing relationship between two points in a digital design, typically between input and output pins of a component or between different components. Timing arcs are essential for defining how signals propagate through the design and are used to calculate the delays associated with different paths.

Types of Timing Arcs:

  1. Combinational Timing Arcs: These arcs describe the delay between an input pin and an output pin of a combinational logic cell, such as a gate (AND, OR, NAND, etc.). These delays are purely combinational and depend on the gate’s characteristics and input conditions.

  2. Sequential Timing Arcs: These arcs represent the timing between the clock edge and the data outputs of sequential elements like flip-flops and latches. They include setup and hold timing requirements at the input pins and clock-to-output delays.

  3. Clock Timing Arcs: These arcs describe the timing characteristics of clock signals, including propagation delay and clock skew. These are critical in determining the overall clock distribution network’s performance within the FPGA.

  4. Interconnect Timing Arcs: These arcs represent the delay across the routing resources between different cells or components within the FPGA fabric.

Importance of Timing Arcs in FPGA Design

Timing arcs are pivotal for several reasons:

  • Static Timing Analysis (STA): Timing arcs are used in STA to verify that all timing paths in the design meet the specified timing constraints. STA checks both setup and hold requirements to ensure that data is sampled correctly at the flip-flop or latch outputs.

  • Design Optimization: By understanding and analyzing timing arcs, designers can optimize their designs to minimize delays on critical paths, thereby improving overall performance.

  • Debugging Timing Violations: Timing arcs help identify paths that do not meet timing constraints (e.g., setup or hold violations), enabling designers to focus on these areas for optimization or redesign.

Analyzing Timing Arcs in Vivado

Vivado provides several commands to analyze and report on timing arcs. The primary commands include get_timing_arcs, report_timing, and various get_* commands for querying design objects.

Key Commands for Timing Analysis in Vivado:

  1. get_timing_arcs Command:

    The get_timing_arcs command retrieves timing arcs for a specified cell or set of cells. It provides details about the timing relationships between pins within a cell.

    get_timing_arcs -of [get_cells <cell_name>]

    • <cell_name>: Replace this with the specific cell name for which you want to get the timing arcs.

    Example:

    To get timing arcs for a flip-flop named ff_inst, use:

    get_timing_arcs -of [get_cells ff_inst]


    This command lists all timing arcs for the flip-flop instance ff_inst, including setup and hold arcs for data input and clock-to-output arcs.

  2. report_timing Command:

    The report_timing command provides detailed timing path analysis from a specific start point to an endpoint. This command can be used to report paths that include specific timing arcs.

    report_timing -from [get_ports <input_port>] -to [get_pins <output_pin>]

    • <input_port>: The starting point of the timing path.
    • <output_pin>: The endpoint of the timing path.

    Example:

    To report timing from an input port data_in to the D input of a flip-flop ff_inst:

    report_timing -from [get_ports data_in] -to [get_pins ff_inst/D]


    This command reports the timing information, including any relevant timing arcs from the input port data_in to the D pin of the flip-flop ff_inst.

  3. Understanding report_timing Outputs:

    The output of report_timing includes:

    • Path Delay: Total delay from the start to the endpoint.
    • Slack: Indicates if the path meets timing constraints (positive slack) or not (negative slack).
    • Segment Details: Each segment of the path is broken down, showing individual cell delays and net delays, which correspond to timing arcs between cells.

Practical Examples of Timing Arc Analysis

Consider a scenario where you have a design with a critical path that goes from an input port data_in to an output port data_out through several logic gates and a flip-flop ff_inst. You want to ensure this path meets timing constraints.

Example Workflow:

  1. Identify Critical Paths:

    Use report_timing to identify critical paths in your design.

    report_timing -from [get_ports data_in] -to [get_ports data_out]


    This command reports all timing paths from data_in to data_out, highlighting critical paths that need optimization.

  2. Inspect Specific Timing Arcs:

    If a flip-flop ff_inst is part of a critical path, use get_timing_arcs to inspect the timing arcs of the flip-flop.

    get_timing_arcs -of [get_cells ff_inst]


    This command provides a list of timing arcs for ff_inst, including setup and hold timing arcs, which are crucial for understanding the flip-flop’s timing requirements.

  3. Analyzing Hold Violations:

    To specifically check for hold violations, use report_timing with the -hold option:

    report_timing -from [get_ports data_in] -to [get_ports data_out] -hold


    This command checks the same path for hold timing, ensuring data stability during the required hold period.

Why Aren’t Timing Arcs Present Everywhere?

Timing arcs are not present everywhere in a design due to several reasons:

  • Optimizations: During synthesis and implementation, non-critical or redundant paths are optimized away to improve performance or reduce area. This may involve eliminating timing arcs that do not contribute to critical path timing.

  • Non-Timing Critical Paths: Paths that do not impact the timing closure are not always analyzed or reported. For instance, paths that do not affect clock domain crossing or are purely for debugging purposes may not have explicit timing arcs reported.

  • Focus on Critical Paths: Timing analysis tools focus on critical or near-critical paths that are most likely to violate timing constraints. Non-critical paths are often ignored to reduce the computational load and focus optimization efforts where needed most.

Optimizing Timing Arcs in Vivado

To optimize timing arcs and paths in your design, consider the following strategies:

  • Logic Optimization: Simplify logic to reduce gate delays, thereby reducing overall path delay.
  • Buffer Insertion: Add buffers to manage signal drive strength and reduce net delays.
  • Placement and Routing Optimization: Optimize the placement of cells and routing paths to minimize interconnect delay.
  • Constraint Management: Ensure that timing constraints are correctly defined to guide the optimization tools effectively.

Conclusion

Timing arcs play a crucial role in the design and analysis of FPGA systems. By using commands like get_timing_arcs and report_timing in Vivado, you can gain insights into the timing relationships within your design, identify critical paths, and optimize them to meet timing constraints. Understanding and managing timing arcs effectively can lead to more reliable and higher-performing FPGA designs.
